Standard color label:
Lovibond?RYBN |
ISO 15305 ，MS252 ：Part 16 ，IP17 M ethod A | Standard configuration： Host, Power Supply, Quick How-to Guide, USB memory cards, standard filters, 1-inch cuvette, 5.25-inch cuvette |
Lovibond RY10: 1 | GB/T 22460，ISO 15305 | |
AOCS RY | AOCS Cc 13b -45 ，AOCS Cc 8d - 55 ，AOCS Cc 13j -97 |
TR 1308--Lovibond Tintometer
Test method | Spectrometer |
Light source | Tungsten halogen lamp |
Wavelength | 380 -780n m |
Photometric measurement range | 0 - 100%T |
Wavelength accuracy | 0.2nm |
Spectral bandwidth | < 15n m |
Photometer linearity | ±0.01%T |
Wavelength | Selection software automatically selects |
Photometer linearity | <0.01%T |
Repeatability | ±0. 5 -%T |
Detector | spectrometer |
Housing | aluminum |
Dimensions | 301m m W x 152m m H x 331m m D |
Weight | 5. 16kg |
Operating environment | up to 90% relative humidity (non-condensing)； + 5 ~ +40°C |
Storage environment | up to 90% relative humidity (non-condensing)； -20 ~ +85°C |
Power supply | 190 -240V |
Data interface | USB ，RS232 |
Certification | CE |
Operating languages | Chinese, English, French, German, Italian, Spanish, Portuguese, Russian, Japanese |
· Especially suitable for automatic measurement of edible oil color
· It can measure Lovibond RYBN color, AOCS RY, Lovibond?RY10:1, chlorophyll, β carotene
· Ensure compliance with relevant international and industry standards
· Measure high-temperature samples (built-in heater)
· Real-time display of sample temperature to avoid measurement in crystalline state
· Convenient and simple integrated operating system
· Chemically resistant housing, suitable for long-term, continuous use in edible oil refineries Aluminum housing, 100% recyclable, meets sustainable development requirements Sealed, easy-to-replace sample measuring cell
· New technologies enable instruments with higher resolution, repeatability, reliability and precision
